Dell PowerEdge FX2 Enclosure

The Dell PowerEdge FX2 Enclosure is a highly flexible, 2U hybrid rack-based platform that combines the benefits of blade density with the cost-effectiveness and simplicity of rack-based systems. It is part of the PowerEdge FX architecture, which is designed to provide a modular approach for IT infrastructure, enabling organizations to tailor their data centers to meet specific computing, storage, and networking requirements. The FX2 enclosure supports a variety of server nodes and storage blocks, providing businesses with greater flexibility to build their infrastructures.

This modular design makes the PowerEdge FX2 ideal for businesses that require high-density servers while maintaining cost efficiency. It enables IT teams to scale their systems easily by adding or removing server nodes, storage, and networking modules as needed.

Features

• Flexible Configuration:
  The FX2 enclosure supports a variety of server nodes and storage configurations, making it highly adaptable to your needs. You can choose from:

  • PowerEdge FC830: A 4-socket server offering exceptional density and expandability.

  • PowerEdge FC630: A 2-socket server providing shared infrastructure in a half-width configuration.

  • PowerEdge FC430: A quarter-width, 2-socket server that maximizes density.

  • PowerEdge FM120x4: The world’s first enterprise-class microserver, designed for compact environments.

  • PowerEdge FD332 Storage Block: Supports up to 16 x SFF 2.5″ storage devices.

• Shared Infrastructure Efficiency:
  The FX2 shares power, cooling, and networking across all server nodes, reducing operational complexity and costs. The enclosure includes:

  • Redundant Power Supply Units (PSUs): 2000W, 1600W, or 1100W AC PSUs in 1+1 redundant or 2+0 non-redundant configurations.

  • Cooling: 8 hot-swappable fans ensure effective cooling of the system.

  • Networking: Offers pass-through modules and I/O options for seamless connectivity.

• Communications Flexibility:
  The FX2 supports several I/O module options, including:

  • Dell PowerEdge FN410s: 4-ports SFP+ 10GbE connectivity.

  • Dell PowerEdge FN410t: 4-port 10Gb Base-T connectivity.

  • Dell PowerEdge FN2210s: 4-port combination Fibre Channel/Ethernet module.

• Systems Management:
  The FX2 is designed for easy, agent-free management using iDRAC8 with Lifecycle Controller, ensuring automated systems management across all server nodes. Chassis Management Controller (CMC) provides centralized management of the enclosure’s resources through a browser-based interface.

• Scalable and Modular:
  The FX2 allows you to scale up as needed, adding more server nodes or storage blocks without disrupting the existing setup. It supports a variety of server node configurations with maximum flexibility

Security

The PowerEdge FX2 is equipped with robust security features to ensure the protection of your infrastructure. These include:

• Integrated Dell Remote Access Controller (iDRAC):
  iDRAC8 with Lifecycle Controller provides agent-free, secure server management. It ensures efficient deployment, configuration, and updates, helping to automate server lifecycle management.

• Secure Management:
  With integrated management tools like the CMC, administrators can manage and monitor resources securely. The chassis also supports advanced security protocols such as Role-Based Access Control (RBAC) and Secure Boot to prevent unauthorized access.

• Encrypted Communications:
  All management interfaces are encrypted using standard protocols, ensuring that all communications within the system are secure from potential external threats.

• Redundant Power and Cooling:
  The FX2’s redundant PSUs and hot-swappable cooling fans help ensure high availability and prevent downtime, a crucial feature in mission-critical environments.

• Firmware Security:
  The system firmware is digitally signed and verified, protecting the platform from malicious code execution.

For more details, you can view the data sheet on our website using the following links: Spec sheet , Technical Guide
